HIROBOT

by darkshinra154-lgtm Node.js Other

Lightweight Whatsapp Bot with Voip Call, Website, and AI Agent. — Built with Baileys and NodeJS 24.

README.md

Open on GitHub

Note

Hirobot is A Lightweight WhatsApp bot that integrates an AI agent, VoIP calling capabilities, and a dedicated web portal for users. Built with Baileys and NodeJS v24+.

Features:

AI Agent Using Gemini.
1:1 Voice & Video Call.
Multi Sessions.
Database Node:Sqlite / Mongodb.
Support AI Rich and Button Message.
Cloudflared Tunnel Website.
Minimal Depedencies.

_{Env
---Project Structure---
HIROBOT
├── 📁lib
│ ├── 📁package
│ │ ├── 📁ai
│ │ ├── 📁voip # Call
│ │ └── 📁website
│ │ ├── 📁views # HTML folder
│ │ └── 📄server.js
│ ├── 📁scrapers
│ ├── 📁utils
│ ├── 📄config.js # bot's preference
│ ├── 📄main.js
│ └── 📄start.js
├── 📁data
│ ├── 📁sessions
│ ├── 📁tunnel
│ └── 📁tmp
├── 📁plugins
├── 📄.env # your tokens
├── 📄CHANGELOG.md
├── 📄LICENSE
├── 📄package.json
└── 📄README.md}

About AI Agent

──────────────

How AutoHeal Works?

MERMAID

flowchart LR
    A@{ shape: odd, label: "User Command" } --> Error
    Error process@==> C@{ shape: diamond, label: "Gemini Server
Gemma-4-31b-it"}
    C --> D@{ shape: circle, label: "⏳" }
    D ==> E[✅ Write and save]
    D ==> F[❌ Stop autoheal]
    E --> G[Done]
    F --> H[Note it as failure]

process@{ animate: true }
style Error stroke:#f00

Gemini 3.1 Lite-Flash	Daily Conversation
Gemini 3.1 Lite	Daily conversation but more complex
Gemma-4-31b-it	AutoHeal system and coding
Gemma-4-26b-a4b-it	AutoHeal system and coding

How to add a new tool

_{All MCP Helper}

Category	Function	Description
Session & Chat History	`getSession(jid)`	get chat history array for a chat
	`resetSession(jid)`	clear chat history for a chat
	`getPinnedNotesReadOnly(jid)`	get notes pinned to a chat
Talking to the AI / Agent Loop	`runAgent(conn, m, text, opts)`	run a full AI turn, get a reply
	`runAgentConfirmed(conn, m, opts)`	resume an agent turn awaiting confirmation
	`callTool(name, args)`	call another registered tool by name
	`listTools() / countTools()`	list / count registered tools
Identity & Permissions	`getUserIdentity(jid, db, conn)`	get sender's name/number/owner/timezone
	`checkGroupAdminOrOwner(groupJid)`	check if sender is group admin/owner
	`readGroupSettings(groupJid)`	read group settings from brain storage
	`readOwnerList()`	list registered bot owners
Persistent Storage ("brain")	`loadBrain() / saveBrain(brain)`	read/write ai-brain.json
Persistent Storage ("brain")	`ensureBrainGroupSlot(brain, jid)`	ensure a group slot exists in brain
Web & Media	`searchWebGrounded(query)`	grounded web search
	`captureWebsiteScreenshot(url)`	screenshot a webpage
	`fetchWebsiteHtmlFallback(url)`	fetch raw HTML of a page
	`peekFetchBuffer(url, headers)`	peek a file buffer from a URL
	`peekfetchVideoBuffer(url, maxBytes, headers)`	peek a video buffer from a URL
	`detectPlatform(url)`	detect platform (YouTube/TikTok/etc)
	`peekAnalyzeWithVision(mediaItems, platform, url, context)`	analyze media with vision model
	`buildMediaPart(m)`	extract image/video/audio from a message
	`fetchSocialMulti(url)`	download helper for social media
	`downloadUserImageAsUrl(m)`	upload user's image, get back a URL
File & Data Tools	`readFileToolCore(file_path, offset)`	core logic behind "read file" tool
	`buildSimpleDiff(oldStr, newStr)`	build a text diff between two strings
	`parseDbKeyPath(key_path)`	parse a dotted key path for db access
Plugin Execution (Advanced/Internal)	`resolvePlugin(command)`	find which plugin matches a command
	`resolveCustomPrefixPlugin(rawInput)`	same, for custom-prefix commands
	`execPluginCommand(command, argsStr, opts)`	run an existing bot plugin/command
	`execEval(code, opts)`	evaluate raw JS code (owner-only, dangerous)
	`classifyPluginRisk(name, plugin)`	classify a plugin's risk level
	`accessLabel(level) / riskBadge(level)`	risk-level label/badge helpers
	`pluginRequirements(plugin)`	get a plugin's access requirements
`getDangerousDocReason(m)`	check if a message/doc looks risky
Error Handling & Internals	`handleError(conn, m, err, pluginName)`	central error handler/reporter
	`isTransientApiError(err)`	check if an API error is transient
	`getApiKeys() / getNextKey() / rotateKey() / resetRateLimit(jid)`	API key pool management
	`normalizeApiKeys(input)`	format/clean a raw API key list
	`getPersonality()`	get bot's configured personality/system prompt
	`MODELS`	map of available AI models
	`setCurrentContext(...)`	internal turn/state management (used by mcp.js itself)
	`hasPending() / confirmPending() / cancelPending()`	internal turn/state management (used by mcp.js itself)

_{JavaScript
/*
ctx() -> Returns the current chat state (always fresh, backed by an
internal module-level object in mcp.js). Common fields:
- currentJid : the id of the chat/user sending the message
- conn : the active WhatsApp connection (for manual sendMessage)
- isOwner : true if the sender is the bot owner
- isROwner : true if the sender is a "real" owner (not fromMe)
- timezone : sender's configured timezone, e.g. "Asia/Jakarta"

Tools import helpers straight from '../mcp.js'. There's no circular-import
issue: mcp.js never statically imports files in ./tools -- it loads them
with a dynamic import() at runtime (see loadToolsDir), so importing mcp.js
from a tool file at the top level is completely safe.
*/
import { ctx, searchWebGrounded } from '../mcp.js'

export default [
{
name: 'check_weather',
description: 'Check the weather for a specific city. Use it when a user asks for the weather, e.g., "What\'s the weather like in Jakarta?"',
parameters: {
city: { type: 'string', description: 'City name, e.g. "Jakarta"', required: true }
},
execute: async ({ city }) => {
const { currentJid } = ctx()
if (!currentJid) return 'Chat context not available'

// const result = await searchWebGrounded(`current weather in ${city}`) // only if you need a helper from mcp.js

return `Weather in ${city}: sunny, 30°C`
}
}
]}

About Website

──────────────

.env Settings for Website

SCENARIO 1 _{No public address, using own domain}	Note _{Your panel does not give a real public address/IP (e.g. Pterodactyl, where the address is just name:port, internal-only). The bot still runs cloudflared (binary auto-downloaded, no manual install) to open a quick tunnel — your custom domain sits in front of it via a Cloudflare Worker + KV Namespace, instead of a regular DNS record.}
	`CF_KV_TOKEN`	Cloudflare API Token with Account > Workers KV Storage > Edit permission, from dash.cloudflare.com/profile/api-tokens
	`CF_ACCOUNT_ID`	Found on the Workers & Pages overview page
	`CF_KV_NAMESPACE_ID`	Found on your KV Namespace's page
	`CF_HOSTNAME`	Required for the domain that becomes your bot's main address, e.g. `bot.yourdomain.com`
SCENARIO 2 _{DNS-pointable server, using own domain}	Note _{Your panel/server can be pointed to via a DNS record (a VPS with a fixed IP, or a panel supporting Cloudflare Named Tunnel / Zero Trust). Requires card verification on Cloudflare Zero Trust (free forever, no charge unless you exceed free-tier limits).}
	`CF_TOKEN`	Named Tunnel token from Cloudflare Zero Trust
	`CF_HOSTNAME`	Required for the domain that becomes your bot's main address, e.g. `bot.yourdomain.com`
SCENARIO 3 _{No own domain, free provider}	Note _{HOSTNAME_PUBLIC — you don't own a custom domain, but have a free public address from another provider (e.g. my.zone.id, is.dev) already pointed (A/CNAME) at your panel's real public address. Fill in only this one, leave everything above empty — the bot will not run cloudflared/any tunnel at all.}
SCENARIO 4 _{Default, nothing configured}	Note Nothing above is filled in — the bot automatically uses a free `trycloudflare.com` URL that changes every time it restarts. No setup required.

Message types

──────────────

📖 Basic

_{JavaScript
conn.reply(m.chat, 'Hello world!', m)

/** @Media
URL — 'https://example.com/audio.mp3'
Local — '/path/to/video.mp4'

@Options
send as document — { document:true }
send as voicenote — { ptt: true }
**/
conn.sendFile(m.chat, media, "file.png", "hello world!", m, { options })

conn.sendContact(m.chat, [
['6281234567890', 'HirooSy'],
['6289876543210', 'Hiro']
], m)

conn.react(m.chat, '👍', m.key)}

📍 Location

_{JavaScript
conn.sendLocation(m.chat, 'https://example.com/thumb.jpg','Title','Address',m)}

🧾 Product

_{JavaScript
/**@Media
String: "https://example.com/img.png" or "./image.png"
Array: [ "https://example.com/", "./img.png" ]
**/

conn.sendProduct(m.chat, media, 'Title', 'Description, m, {
businessOwnerJid: "[email protected]",
currencyCode: 'USD',
priceAmount1000: 20,
retailerId: 'Code Promo',
})}

🖼️ Url Preview

_{JavaScript
conn.sendUrlPreview(
m.chat,
'https://example.com/thumb.jpg',
'https://example.com Hello World!',
'Url Preview Title',
'Url Description',
'IMAGE', // true for highQuality, or ['IMAGE', true]
m
)}

🛒 Carousel

_{JavaScript
conn.sendButton(m.chat, {
text: 'Interactive with Carousel!',
footer: 'HirooSy',
cards: [
{
image: { url: './path/to/image.jpg' },
caption: 'Image 1',
footer: 'Image 1',
nativeFlow: [{ text: 'Source', url: 'https://example.com', useWebview: true }]
},
{
image: { url: 'https://example.com/image.png' },
caption: 'Image 2',
footer: 'Image 2',
ltoText: 'New Coupon!',
ltoCode: 'HiroBot',
ltoUrl: 'https://example.com',
nativeFlow: [{ text: 'Source', url: 'https://example.com' }]
}
]
}, m)}

🔖 NativeFlow Button

_{JavaScript
conn.sendButton(m.chat, {
image: { url: './path/to/image.jpg' },
caption: 'Interactive!',
footer: 'My Bot',
optionText: 'Select Options',
optionTitle: 'Select Options',
ltoText: 'HirooSy',
ltoCode: 'Hiro bot',
ltoUrl: 'https://example.com',
nativeFlow: [
{ text: '👋🏻 Greeting', id: '#Greeting' },
{ text: '📞 Call', call: '628123456789' },
{ text: '📋 Copy', copy: 'Hiro bot' },
{ text: '🌐 Source', url: 'https://example.com', useWebview: true },
{
text: '📋 Select',
sections: [
{ title: '✨ Section 1', rows: [{ header: '', title: '🏷️ Coupon', description: '', id: '#CouponCode' }] },
{ title: '✨ Section 2', highlight_label: '🔥 Popular', rows: [{ header: '', title: '💭 Secret Ingredient', description: '', id: '#SecretIngredient' }] }
],
}
]
}, m)}

🗓️ AI Rich

_{JavaScript
await conn.aiRich()
.setTitle('Ai Rich Message')
.addText('[HyperLink](https://example.com)\nCitation [](https://example.com)'\n[x^2+y^2=r^2|100|100](https://example.com/latex.png))
.addImage('https://example.com/image.png')
.addCode('javascript', `console.log('Hello World')`)
.addHtml(["<html>Hello world</html>", "Tab 1"], ["<html>Hi twin</html>", "Tab 2"]),
.addTable([
['Name', 'HirooSy'],
['Bio', 'Im developer'],
['Age', '67']
])
.addSource([['https://example.com/favicon.ico', 'https://example.com', 'Source']])
.addTip('Tip Text')
.addSuggest(['Continue', 'Cancel'])
.send(m.chat, { quoted: m })

// animated progress
await conn.aiRich()
.addProcess("Loading...")
.send(m.chat)}

📦 Sticker

_{JavaScript
/** @Media
URL — 'https://example.com/image.png'
Local — '/path/to/image.png'
**/

// Sticker
conn.sendSticker(m.chat, media, { packname: "Hiro", author: "Bot" }, m)

// StickerPack
conn.sendStickerPack(m.chat, {
cover: { url: media },
stickers: [
{ data: { url: media } },
{ data: { url: media } },
],
name: 'My Sticker Pack',
publisher: 'Publisher stickerpack',
description: 'Description pack'
})}

📞 Call

_{JavaScript
/** @Media
URL — 'https://example.com/audio.mp3'
Local — '/path/to/video.mp4'
**/

// Audio
const call = await conn.call('628123456789', media)

// Video
const call = await conn.call('628123456789', media, {
videoSource: media
})

// Silent
const call = await conn.call('628123456789', 'silence')

// Audio as video call
const call = await conn.call('628123456789', Audio, {
isVideo: true
})}

Install and Run

REQUIREMENT	Server	100% CPU Limit, 700MB RAM, 1GB Storage `-`
	NodeJS	24 or higher `pkg install nodejs`
	Python	Python 3.10+ `pkg install python`
	FFMPEG	latest `pkg install ffmpeg`

_{Bash
$ git clone https://github.com/HirooSy/HIROBOT.git
$ cd HIROBOT
$ mv .env.example .env
$ nano .env
$ node .}
